HCQ5080ZXXGL5 Model technical parameters | |||
Name: | HCQ5080ZXXGL5 | Exterior size(mm): | 5400,5900×2150×2490 |
Chassis: | EQ1082GLJ2 | Container size(mm): | ×× |
Total weight :(kg) | 8250 | Approach angle/ Departure angle(° ) | 24/10,24/12 |
Payload:(kg) | 3700 | Front suspension/rear suspension(mm): | 1070/1030,1180/920 |
Kerb Mass:(kg) | 4355(Kg) | Max Speed(km/h): | 90 |
Chassis parameters | |||
Chassis: | EQ1082GLJ2 | Axle weight: | 3000/5250 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3300,3800,3950,4500 | Fronttread(mm): | 1506,1590,1750,1770 |
Max people in cab: | 3 | Rear tread(mm): | 1530,1586,1650 |
Number of tires: | 6 | Number of spring axle: | 8/9+5,8/10+7,9/10+8 |
Tire Type: | 7.50-16LT 14PR,7.50R16LT 14PR,8.25-16LT 12PR,8.25R16LT 12PR | ||
introduction: | 1.随底盘选装同系列排半驾驶室,选装前面板新风格;2.外形尺寸对应关系(外长/轴距/后悬):5400/3300/1030(920),5900/3800/1030(920);3.侧防护,后防护材料为Q235,后防护离地高度为490mm,断面尺寸为 130×50mm,侧防护连接方式为螺栓连接,后防护与车辆焊接连接;4.ABS型号为3631010-C2000,生产厂家为东科克诺尔商用车制动系统(十堰)有限公司;5.油耗申报值(L/100km)为与发动机型号一一对应:CY4SK251/17.7,YC4FA130-50/18.0,CY4BK151/18.2;6.该车用于垃圾的收集清运,主要专用装置为勾臂. |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
CY4BK151 CY4SK251 YC4FA130-50 4DX23S-130E5 |
东风朝阳朝柴动力有限公司 东风朝阳朝柴动力有限公司 广西玉柴机器股份有限公司 一汽解放汽车有限公司无锡柴油机厂 |
3856 3856 2982 3857 |
105 115 95 97.5 |
other parameters |
Introduction: |
more Picture: |
※ Need more information or pictures?please contact us and we will provide best service!。 |
