HCQ5165ZXXDE5 Model technical parameters | |||
Name: | HCQ5165ZXXDE5 | Exterior size(mm): | 7050,6500×2500×2900,3050 |
Chassis: | EQ1165LJ9BDE | Container size(mm): | ×× |
Total weight :(kg) | 16000 | Approach angle/ Departure angle(° ) | 19/12 |
Payload:(kg) | 8900 | Front suspension/rear suspension(mm): | 1230/1320 |
Kerb Mass:(kg) | 6905(Kg) | Max Speed(km/h): | 90 |
Chassis parameters | |||
Chassis: | EQ1165LJ9BDE | Axle weight: | 5600/10400 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3950,4500,4700,3400,3700,5200,5600 | Fronttread(mm): | 1858,1949,1765,1891 |
Max people in cab: | 3 | Rear tread(mm): | 1806,1865,1750 |
Number of tires: | 6 | Number of spring axle: | 8/10+7 |
Tire Type: | 9.00R20,10.00R20 | ||
introduction: | 侧防护采用碳钢/Q235,焊接连接,后防护采用碳钢/Q235,螺栓连接,截面尺寸为150×30,离地高为470mm。车辆长/轴距/车高对应关系:7050/4500/3050,6500/3950/2900。ABS系统生产厂家,型号 :焦作博瑞克控制技术有限公司,J ABS。安装具有卫星定位功能的行驶记录仪。发动机/油耗值对应关系为: YCD4P4S-170/26.6,ISB210 50/26.5,ISD160 50/26.3,ISB180 50/27.8,YCD4P4S-140/26.6,YC4EG170-50/26.0,YC4EG185-50/26.3;该车专用装置为勾臂,用于城市垃圾运输. |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
YC4EG170-50 YC4EG185-50 ISB180 50 ISD160 50 ISB210 50 YCD4P4S-170 YCD4P4S-140 YC4S160-50 |
广西玉柴机器股份有限公司 广西玉柴机器股份有限公司 东风康明斯发动机有限公司 东风康明斯发动机有限公司 东风康明斯发动机有限公司 广西玉柴动力机械有限公司 广西玉柴动力机械有限公司 广西玉柴机器股份有限公司 |
4730 4730 5900 4500 5900 4580 4580 3767 |
125 136 132 118 155 125 105 118 |
other parameters |
Introduction: |
more Picture: |
※ Need more information or pictures?please contact us and we will provide best service!。 |
